TP-35C Automatic N Fold Hand Towel Paper Packing Machine

Brand Name: IMAKO
Price: Negotiable
Model Number: TP-35C
Power: 10KW
Application: N/Z Fold Hand Towel Paper and Napkins
Weight: 3600KG
Output: 35Pack/Min
Packaging dimension: Length (L): 150~300 Width (W): 110~250 Height (H): 70~115 mm
Place of Origin: CHINA.
Certification: CE, ISO
Minimum Order Quantity: 1 SET
Trading Method: FOB/CIF/EXW Xiamen Port
Delivery Time: 90 Days
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.

Get Quote

+86-15918973337

★Using prefabricated cylinder roll film, thermos transfer printer, ink wheel coding machine and ribbon coding machine can be pre-installed.

TP-35C main parameter configuration
Scope of application	N fold hand towel	Roll film correction	Automatic correction
Feeding mode	Automatic feeding	Machine weight(KG)	3600
Packaging material install structure	Air shaft	Packing film type	Prefabricated bag roll film
Film roll diameter(mm)	≤600	Power supply	380V/50Hz
Machine size(mm)	L3000W1800H1850	Compressed Air (mpa)	Air source≥0.5, Air flow≥300L / min
Bag cutting mode	Insert cutting	Total power(KW)	10
Pronghorn molding	forming mould	Options	Printer,perforation device

The paper towel arrangement, feeding, filling, pulling, conveying and sealing are controlled by servo motors. It is simple to operate and convenient for maintenance.

Products Categories

Related Products

More》

Hand Towel Packing Machine Towel Paper Packing Machine Hand Paper Packing Machine

TP-35C Automatic N Fold Hand Towel Paper Packing MachineMain Parts

1. Conveying line

The Frequency conversion motor drives the conveyor belt to feed material, with photoelectric eye automatic counting function, cam-controlled push and pallet mechanism, automatic feeding blocking protection function, automatic alarm function.

2. Machine Base

The structure of the base determines the stability of the whole machine .

3. Servo motor

We use a reliable brand to ensure smooth operation at low and high speeds and accurate positional accuracy.

Manufacturer Advantage We have strong power to support our production, from factory environment construction to equipment
configuration, all leading to high quality products.

Cost savings

By automating the paper towel packaging process, businesses can save time, labor costs, and materials. This can result in significant cost savings over time, allowing companies compete more effectively in the marketplace.

Efficient Reaction

24 hours online service is hard but our team loves to help our customers solve problems, that what we try to do.

Good Quality

We have strict quality control processes in place to ensure that TP-35C Automatic N Fold Hand Towel Paper Packing Machine are of the highest quality. and passed CE, ISO 9001, etc.
